JIC Straight Insert - UN/UNF Male (Cone 37°)

ISO12151-5-S – AGJ

Datasheets
30382
End type 03, 03
Size Range (mm) 6 - 19 mm
Hose fitting type Push Lok
Size Range (inch) 1/4" inches - 3/4" inches
Product Classification Hydraulics
Product Category Hose Fittings
Product Group Push-Lok Hose Fittings
Product Program Low Pressure - Push-Lok
Web Article
Push-Lok
Show fullscreen image
Hymatik number Supplier Item Number
Note
Material
End 1 Thread Size
End 1 Thread Type
End 1 Tube Sizes
Weight
TariffNumber
Country of origin
Hose Size
Unit price
Stock status
Favorite Sort Order
H00071848 30382-4-4 30382 - 1/4" Insert (ST) - 6 (7/16") UNF JIC M Steel 7/16" x 20 UNF 6 mm, 1/4" 0.015, KG 73079910 US, USA 1/4" | 6.3 mm | DN: 6 15.54 EUR Not in stock
Minimum 25
 2147483647
H00071849 30382-6-6 30382 - 3/8" Insert (ST) - 10 (9/16") UNF JIC M Steel 9/16" x 18 UNF 10 mm, 3/8" 0.025, KG 73079910 US, USA 3/8" | 10 mm | DN: 10 17.34 EUR Not in stock
Minimum 25
 2147483647
H00071850 30382-8-8 30382 - 1/2" Insert (ST) - 12 (3/4") UNF JIC M Steel 3/4" x 16 UNF 12 mm, 1/2" 0.0608, KG 73079910 US, USA 1/2" | 12.5 mm | DN: 12 52.62 EUR Not in stock
Minimum 5
 2147483647
H00071851 30382-12-12 30382 - 3/4" Insert (ST) - 18, 20 (1 1/16") UNF JIC M Steel 1 1/16" x 12 UNF 18 mm, 20 mm, 3/4" 0.121, KG 73079910 US, USA 3/4" | 19 mm | DN: 19 130.76 EUR Not in stock
Minimum 10
 2147483647
H00071852 30382-6-6B 30382 - 3/8" Insert (B) - 10 (9/16") UNF JIC M Brass 9/16" x 18 UNF 10 mm, 3/8" KG 3/8" | 10 mm | DN: 10 Not in stock 2147483647
H00071853 30382-8-8B 30382 - 1/2" Insert (B) - 12 (3/4") UNF JIC M Brass 3/4" x 16 UNF 12 mm, 1/2" KG 1/2" | 12.5 mm | DN: 12 Not in stock 2147483647
H00071854 30382-12-12B 30382 - 3/4" Insert (B) - 18, 20 (1 1/16") UNF JIC M Brass 1 1/16" x 12 UNF 18 mm, 20 mm, 3/4" KG 3/4" | 19 mm | DN: 19 Not in stock 2147483647
H00387222 30382-12-12B-SM Metric Wrench Size Brass 3/4" | 19 mm | DN: 19 Not in stock 2147483647
H00387223 30382-4-4B-SM Metric Wrench Size Brass 1/4" | 6.3 mm | DN: 6 Not in stock 2147483647
H00387224 30382-5-4B-SM Metric Wrench Size Brass 1/4" | 6.3 mm | DN: 6 Not in stock 2147483647
H00386186 30382-6-8B Brass 1/2" | 12.5 mm | DN: 12 Not in stock 2147483647
H00386187 30382-8-8B-SM Metric Wrench Size Brass 0.0568, KG 74122000 DE, Germany 1/2" | 12.5 mm | DN: 12 95.95 EUR Not in stock
Minimum 5
 2147483647
