Ball Valve - 1/4” 2-Way - QS Series

Datasheets
Ball Valve 1 4” 2 Way QS Series
Product Classification Process
Product Category Valves
Product Group High Pressure AE Valves
Product Program Ball Valves
Product Subprogram Ball Valves 2-Way
Show fullscreen image
Hymatik number Supplier Item Number
Valve Model
A Inch
A (mm)
B Inch
B (mm)
C Inch
C (mm)
D Inch
D (mm)
E Inch
E (mm)
F Inch
F (mm)
G Inch
G (mm)
H Inch
H (mm)
J Inch
J (mm)
K Inch
K (mm)
L Inch
L (mm)
Block Thickness Inch
Block Thickness (mm)
End Connection Number
Connection
Mawp Room Temperature Psi
Mawp Room Temperature Bar
Seat Dland Hex Inch
Seat Dland Hex (mm)
Weight
Note
Unit price
Stock status
Favorite Sort Order
H00058308 2B4S15Q4 2B4S 4.33 109.99 4.19 106.49 2 50.80 3.37 85.55 3.90 99.02 1.13 28.58 1.50 38.10 0.75 19.05 0.43 10.92 0.28 7.11 1.91 48.41 1 25.40 Q4 QS250 15000 1034 1 25.40 Not in stock 2147483647
H00058309 2B4S15Q4-AO 2B4S 4.33 109.99 4.19 106.49 2 50.80 3.37 85.55 3.90 99.02 1.13 28.58 1.50 38.10 0.75 19.05 0.43 10.92 0.28 7.11 1.91 48.41 1 25.40 Q4 QS250 15000 1034 1 25.40 KG Air-to-open/spring to close Not in stock 2147483647
H00058310 2B4S15Q4-AC 2B4S 4.33 109.99 4.19 106.49 2 50.80 3.37 85.55 3.90 99.02 1.13 28.58 1.50 38.10 0.75 19.05 0.43 10.92 0.28 7.11 1.91 48.41 1 25.40 Q4 QS250 15000 1034 1 25.40 KG Air-to-close/spring to open Not in stock 2147483647
H00058311 2B4S15Q4-EO1 2B4S 4.33 109.99 4.19 106.49 2 50.80 3.37 85.55 3.90 99.02 1.13 28.58 1.50 38.10 0.75 19.05 0.43 10.92 0.28 7.11 1.91 48.41 1 25.40 Q4 QS250 15000 1034 1 25.40 KG 120 volt AC 50/60 Hz Not in stock 2147483647
H00058312 2B4S15Q4-EO2 2B4S 4.33 109.99 4.19 106.49 2 50.80 3.37 85.55 3.90 99.02 1.13 28.58 1.50 38.10 0.75 19.05 0.43 10.92 0.28 7.11 1.91 48.41 1 25.40 Q4 QS250 15000 1034 1 25.40 KG 220 volt AC 50/60 Hz Not in stock 2147483647
H00058313 2B4S15Q4-EO3 2B4S 4.33 109.99 4.19 106.49 2 50.80 3.37 85.55 3.90 99.02 1.13 28.58 1.50 38.10 0.75 19.05 0.43 10.92 0.28 7.11 1.91 48.41 1 25.40 Q4 QS250 15000 1034 1 25.40 KG 24 VDC Not in stock 2147483647
H00058314 2B4S15Q6 2B4S 4.33 109.99 4.19 106.49 2 50.80 3.37 85.55 3.90 99.02 1.13 28.58 1.50 38.10 0.75 19.05 0.43 10.92 0.28 7.11 1.91 48.41 1 25.40 Q6 QS375 15000 1034 1 25.40 Not in stock 2147483647
H00058315 2B4S15Q6-AO 2B4S 4.33 109.99 4.19 106.49 2 50.80 3.37 85.55 3.90 99.02 1.13 28.58 1.50 38.10 0.75 19.05 0.43 10.92 0.28 7.11 1.91 48.41 1 25.40 Q6 QS375 15000 1034 1 25.40 KG Air-to-open/spring to close Not in stock 2147483647
H00058316 2B4S15Q6-AC 2B4S 4.33 109.99 4.19 106.49 2 50.80 3.37 85.55 3.90 99.02 1.13 28.58 1.50 38.10 0.75 19.05 0.43 10.92 0.28 7.11 1.91 48.41 1 25.40 Q6 QS375 15000 1034 1 25.40 KG Air-to-close/spring to open Not in stock 2147483647
H00058317 2B4S15Q6-EO1 2B4S 4.33 109.99 4.19 106.49 2 50.80 3.37 85.55 3.90 99.02 1.13 28.58 1.50 38.10 0.75 19.05 0.43 10.92 0.28 7.11 1.91 48.41 1 25.40 Q6 QS375 15000 1034 1 25.40 KG 120 volt AC 50/60 Hz Not in stock 2147483647
H00058318 2B4S15Q6-EO2 2B4S 4.33 109.99 4.19 106.49 2 50.80 3.37 85.55 3.90 99.02 1.13 28.58 1.50 38.10 0.75 19.05 0.43 10.92 0.28 7.11 1.91 48.41 1 25.40 Q6 QS375 15000 1034 1 25.40 KG 220 volt AC 50/60 Hz Not in stock 2147483647
H00058319 2B4S15Q6-EO3 2B4S 4.33 109.99 4.19 106.49 2 50.80 3.37 85.55 3.90 99.02 1.13 28.58 1.50 38.10 0.75 19.05 0.43 10.92 0.28 7.11 1.91 48.41 1 25.40 Q6 QS375 15000 1034 1 25.40 KG 24 VDC Not in stock 2147483647
H00058320 2B4S15Q4-HT 2B4S 4.33 109.99 4.19 106.49 2 50.80 3.37 85.55 3.90 99.02 1.13 28.58 1.50 38.10 0.75 19.05 0.43 10.92 0.28 7.11 1.91 48.41 1 25.40 Q4 QS250 15000 1034 1 25.40 KG for media temperature up to 500˚F (260˚C) Not in stock 2147483647
H00058321 2B4S15Q6-HT 2B4S 4.33 109.99 4.19 106.49 2 50.80 3.37 85.55 3.90 99.02 1.13 28.58 1.50 38.10 0.75 19.05 0.43 10.92 0.28 7.11 1.91 48.41 1 25.40 Q6 QS375 15000 1034 1 25.40 KG for media temperature up to 500˚F (260˚C) Not in stock 2147483647
