Enerpac V-152 Trykregulator

Enerpac Pressure Relief Valve:

• Limits pressure developed by the pump in hydraulic circuit, thus limiting the force imposed on other components
• 800-10,000 psi adjustment range; ± 3% repeatability
• Valve opens whenever preset pressure is reached. To increase pressure setting, turn handle clockwise
• Max. oil flow 1830 in3 /min • Includes 3 ft. return line hose kit
• Used to automate clamp cycles, prevent pressure loss and provide additional operator and component safety
• Regulate oil flow or system pressure
• All valves feature NPT or SAE porting to insure against leakage at rated pressure
• Can easily be installed in any system
• All valves are painted, coated or plated for corrosion resistance
