Nåleventil - Mikrometerskrue - 60VRMM

Needle Valve Micrometering

Hymatik varenr.	Leverandør varenr.	Oprindelsesland	TariffNumber	Vægt	A Inch	A (mm)	B Inch	B (mm)	Outside Diameter Tube Inch	Outside Diameter Tube (mm)	C Inch	C (mm)	D Inch	D (mm)	E Inch	E (mm)	F Inch	F (mm)	G Inch	G (mm)	Block Thickness Inch	Block Thickness (mm)	Orifice Diameter Inch	Orifice Diameter (mm)	G1 Inch	G1 (mm)	H Inch	H (mm)	M Inch	M (mm)	N Inch	N (mm)	Rated CV	Pressure Rating Psi Room Temperature	Pressure Rating Bar Room Temperature	Enhedspris	Lagerstatus	Sort Order
H00058952	60VRMM4812	US, USA	84818073	1, KG	2	50.80	1	25.40	1/4	6.35	0.50	12.70	1.31	33.27	2.63	66.80	3	76.20	0.97	24.63	1	25.40	0.06	1.57	0.22	5.58	6.06	153.92	0.69	17.25	0.38	9.65	0.00	60000	4137	7106,55 DKK	Ikke på lager	2147483647
H00058953	60VRMM6812	US, USA	84818073	0, KG	2	50.80	1	25.40	3/8	9.53	0.53	13.46	1.31	33.27	2.63	66.80	3	76.20	0.97	24.63	1	25.40	0.06	1.57	0.22	5.58	6.06	153.92	0.69	17.25	0.38	9.65	0.00	60000	4137	6467,22 DKK	Ikke på lager	2147483647
